Schneider Electric SCHN Current transformer

Schneider Electric External Current Transformer LV429521

Manufacturer: Schneider Electric
Designation: External Transformer 25/100A Neutral Point
Type: LV429521
Design: Through-current transformer
Primary Rated Current In: 100 A
Secondary Rated Current: 5 A
Secondary Rated Power: 1.6 VA
Accuracy Class: 1
Calibrated: yes
With Touch Protection: yes
Snap Mounting: no
With Copper Busbar: yes
Secondary Connection: Screw Connection
Number of Primary Inputs: 1

This is an external current transformer for neutral conductors (ENCT) for ComPact NSX100-250 with Micrologic 5/6 trip units. For three-pole devices, the distributed neutral conductor of the system can be protected by installing this external sensor. The rated current of the sensor ranges from 25 A to 100 A. The ENCT must be connected to the Micrologic trip unit via a shielded twisted pair cable. The maximum cable length is 10 m and the cross-section must be between 0.4 mm² and 1.5 mm².
