Schneider Electric Operating hours counter

Schneider Electric Operating Hour Counter XB5DSB

Manufacturer: Schneider Electric
Designation: Operating hour counter
Type: XB5DSB
Mounting type: Surface and front mounting
Execution: Digital
Counting range: 9999 h
Reset function: None
Running display: Yes
Number of digits: 5
Input voltage: 12-24 V
Voltage type: AC/DC
Input voltage frequency: 50-60 Hz
Drive type: Net synchronous
Width: 30 mm
Height: 30 mm
Installation depth: 60 mm
Front panel width: 30 mm
Front panel height: 30 mm
Front mounting cutout diameter: 22.5 mm
Mounting up to max. wall thickness: 6 mm
Protection class (IP): IP65
Protection class (NEMA): 13

Schneider Electric Operating Hour Counter XB5DSB: Additional details
The Harmony XB5 series made of plastic offers a wide range of 22 mm complete devices such as push buttons, indicator lights, and selector switches, including emergency stop switches. Additionally, due to the modular design of the devices, all components can also be obtained as individual elements, and optionally for 30 mm installation size. Due to their quality, flexibility, and extreme robustness, the devices are ideally suited for most applications in industry and buildings. Installed in a 22 mm hole, the device is connected via screw terminals on the back of the product. This operating hour counter features a 5-digit display without a reset function. The supply voltage is 12-24 V AC/DC. Due to the variety of existing product standards and certifications, it is suitable for international use. Thanks to the Green Premium environmental label, you can obtain detailed information on material contents, environmental impacts, and circular economy that support your sustainability goals.
