Schneider Electric C113050LS Switch disconnector ComPacT NSXm NA 3P 50 A

Schneider Electric Load Break Switch ComPacT C113050LS

Manufacturer: Schneider Electric
Designation: Load Break Switch ComPacT NSXm NA, 3P, 50 A
Type: C113050LS
Design as Main Switch: yes
Design as Maintenance/Repair Switch: yes
Design as Safety Switch: no
Design as Emergency Stop Device: no
Design as Reversing Switch: no
Number of Switches: 1
Max. Rated Operating Voltage Ue at AC: 690 V
Rated Operating Voltage: 690 V
Rated Continuous Current Iu: 50 A
Rated Continuous Current at AC-23, 400 V: 50 A
Rated Continuous Current at AC-21, 400 V: 50 A
Rated Short-Circuit Strength Icw: 0.9 kA
Number of Poles: 3
Number of Auxiliary Contacts as Changeover: 2
Motor Drive Optional: no
Integrated Motor Drive: no
Voltage Release Optional: yes
Device Design: Built-in Device Fixed Installation
Suitable for Floor Mounting: yes
Suitable for Front Mounting 4-Hole: yes
Suitable for Central Front Mounting: no
Suitable for Panel Installation: yes
Suitable for Intermediate Installation: no
Color of Operating Element: black
Design of Operating Element: Knob
Lockable: no
Connection Type Main Circuit: Screw Connection
Protection Class (IP), front side: IP40

This is a Load Break Switch ComPacT NSXm NA 50A, category AC-22A/AC-23A. It has been designed to ensure reliable isolation switching. It offers new features such as Everlink technology, DIN rail and panel mounting capability. It integrates new spring-type auxiliary devices that are externally visible. This 3-pole version is compatible with the accessories and additional equipment of the ComPacT NSXm circuit breakers. The ComPacT NSXm NA has the same footprint as the ComPacT NSXm circuit breakers, measuring 81 mm (W) x 137 mm (H) x 80 mm (D). It ensures compliance with international standards (IEC 60947/CCC/EAC) and marine specifications.
