Pipelife Ceiling box U86K DVD-2 SP-97378101

Spelsberg ceiling box U 86 K DVD-2

Manufacturer: Spelsberg
Designation: Ceiling box U86K
Type: U 86 K DVD-2
Mounting type: Concrete construction
Shape: Round
Construction: Other
Version: Single
With rotating ring: No
Couplable: No
Mounting: Without
Diameter: 74 mm
Length: 74 mm
Width: 74 mm
Depth: 106 mm
Internal depth: 74 mm
With screws: No
Housing feed-through through knock-out opening: No
Housing feed-through through sealing diaphragm: No
Housing feed-through through pipe socket: No
Housing feed-through through stepped diaphragm: No
For pipe diameter: 25 mm
Suitable for cable diameter: 1 to 26 mm
Pipe locking: Yes
Pipe locking optional: No
Entry from rear: No
Number of entries: 8
Material: Plastic
Halogen-free: Yes
Surface protection: Untreated
Colour: Other
Protection class (IP): IP30
Cover version: Dummy cover
Transparent cover: No
Cover fixing: Snap-on
Sealable: No
Functional integrity: Without
With shielding: No
Airtight: Yes
Terminal position-fixed: No
Luminaire hook fastening: Yes
Spigot: Without
With nail straps: No
Special application: Without

Spelsberg ceiling junction box U 86 K DVD-2: further details
Ceiling junction box for panel ceilings up to 4.5 cm thick, with M5 threaded socket (load capacity 10 kg) to accept a ceiling hook. Lamp wattage LED max. 3 W, lamp wattage halogen max. 6.5 W. The use of the U86 as a luminaire installation box in large components, such as panel ceilings or filigree ceilings, does not correspond to the recognized state of the art. The installation tolerances permitted there generally do not allow precise installation, with protection class IP30, rated insulation voltage: 400V AC, halogen-free, adhesive fastening or nail fastening, membrane for perforation, sealing range M16-M25. Dimensions: 74 x 74 x 106 mm.
