Product details
The VAL-SEC-T2-2C-175-FM 2905350 from Phoenix is a high-quality plug-in surge arrester specifically designed for 2-phase power supply networks. It provides effective protection against surges and is suitable for use in systems with combined PE and N in a single conductor. With a protection level of 0.85 volts, this surge arrester ensures reliable safeguarding of electrical devices and installations. The integrated remote signaling contact allows for easy monitoring of the device's status. Made in Germany, the VAL-SEC-T2-2C-175-FM meets the requirements of test class Type 2 and offers a nominal discharge current capacity of 20 kA, making it a robust choice for protection against lightning strikes and other surge events.
- Protection level of 0.85 volts for effective surge protection
- Integrated remote signaling contact for status monitoring
- Nominal discharge current of 20 kA for high durability
- Suitable for 2-phase power supply networks with combined PE and N.
Surge protection type | Surge arrester |
Number of conductors | 1 x |
Test class | Type 2 |
Item number | 34045068 |
Manufacturer | Phoenix |
Category | Surge protection |
Manufacturer no. | 2905350 |
Release date | 17.5.2023 |
Colour | Grey |
Exact colour description | Light grey |
Material group | Plastic |
Material | Polyamide |
Surge protection type | Surge arrester |
Number of conductors | 1 x |
Lightning impulse current | 20 kA |
Rated leakage surge current | 20 kA |
Nominal voltage | 120 V |
Protection level | 0.85 V |
Test class | Type 2 |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 0.07 m |
Width | 0.10 m |
Height | 0.10 m |
Weight | 214.40 g |
Specifications may include unverified machine translations.
