Product details
Space-saving installation due to a narrow construction width of 6.2 mm. Signaling without additional auxiliary energy thanks to a mechanical status display. An optional telecommunication module monitors up to 40 articles without additional wiring. Simple interruption of signal circuits for maintenance work is made possible by vertical blade separation. Safe behavior in the event of overload is ensured by an integrated disconnection device. Grounded or insulated shield earthing is facilitated by the third clamping point on the surge protection device.
Surge protection type | Surge arrester |
Item number | 10259775 |
Manufacturer | Phoenix Contact |
Category | Surge protection |
Manufacturer no. | 2906769 |
Release date | 19.12.2018 |
Colour | Grey |
Exact colour description | Grey |
Material group | Plastic |
Material | Polybutylene terephthalate (PBT) |
Surge protection type | Surge arrester |
Lightning impulse current | 20 kA |
Nominal voltage | 12 V |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂ emissions | 1.94 kg |
Climate contribution | CHF 0.11 |
Length | 0.11 m |
Width | 0.08 m |
Height | 0.08 m |
Weight | 36.74 g |
