OBO Bettermann Cable gland, divisible V-TEC TB20 2x4

Ratings
BrandMore from OBO Bettermann
Delivered between Fri, 22.5. and Fri, 5.6.
Free shipping starting at 50.–

Product details

OBO Bettermann Cable Gland, divisible V-TEC TB20 2x4

Manufacturer: OBO Bettermann
Description: Divisible cable gland
Seal insert: multiple
Type: V-TEC TB20 2x4
Thread type: metric
Thread nominal size metric/PG: 20
Thread pitch: 1.5 mm
Thread length: 10 mm
Wrench size: 30 mm
Hexagon corner dimension: 30 mm
Material: Plastic
Material quality: Polycarbonate (PC)
Surface protection: untreated
Halogen-free: yes
Fiberglass reinforced: no
Protection class (IP): IP67
Impact resistant: yes
Color: gray
Bending protection: no
With counter nut: yes
Design: straight
Multiple seal insert: yes
Flat cable gland: no
With strain relief: no
Type of seal: O-ring
Divisible gland: yes
Operating temperature: -20..80 °C
Explosion-proof version: no
For Ex-zone gas: none
For Ex-zone dust: none

The divisible cable gland V-TEC TB ensures, like all V-TEC glands, a secure sealing of the cables. The installation of, for example, pre-assembled cables or functional lines is easy and quick due to the divisibility of the cable gland. The V-TEC TB is also unbeatable for retrofitting an existing installation as well as for repair applications; it can be installed without disassembling pre-installed cables and without interrupting ongoing production.

Key specifications

Colour
Grey
Cable connection type
Cable gland
Clamps diameter
20 mm
Suitable for cable cross-section
8 mm²
Items per sales unit
1x

General information

Item number
31351464
Manufacturer
OBO Bettermann
Category
Cable joints
Manufacturer no.
2024950
Release date
24.9.2022
External links
Manufacturer's site (de)

Colour

Exact colour description
Grey
Colour
Grey

Material

Material
Polycarbonate (PC)
Material group
Plastic

Cable connection Properties

Cable connection type
Cable gland
Clamps diameter
20 mm
Suitable for cable cross-section
8 mm²
Plug type
Flat

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
16.89 kg
Climate contribution
CHF 0.40

Safety

Protection type (IP code)
IP67

Scope of delivery

Scope of delivery
Cable gland
Items per sales unit
1x

Product dimensions

Length
10 mm
Width
30 mm
