NZR Electr.DIN rail meter

Three-phase meter EcoCount SL 85A, M-BUS, 0.25-585A, MID compliant. The EcoCount SL meter, designed for direct measurement, is a fully electronic electricity meter for fixed installation in three-phase four-wire networks or single-phase two-wire networks, intended to measure electrical active energy and register it in up to two energy tariffs. It is an indoor meter designed as a built-in device for rail mounting, with a compact design of only a few modular units. The meter features a backlit display, menu navigation via two control buttons, and displays active, reactive, and apparent power, power factor, voltage, network frequency, and current totals as well as per phase. It includes alarm functionality with parameterizable thresholds, tariff switching, reading, a resettable meter register, phase failure detection, rotation field detection, reverse flow prevention, and compliance assessment according to MID. The display capacity dynamically adjusts to consumption. Initially, it shows 5.3 for whole and decimal places. As consumption increases, the decimal point shifts up to a representation of 8.0, modular units, M-BUS, and S0 pulse output, future-proof with an expansion interface for additional functions via EcoCount SL 85 modules, MID, M-Bus.
