Merten Angled outlet

Merten Angled Outlet pws/gl 464919

Manufacturer: Merten
Description: Angled outlet pws/gl for data connection
Type: 464919
Composition: Base element with central cover plate
Usage: other
Mounting ring: yes
With dust protection: no
With hinged cover: no
Outlet direction: angled
Labeling field: without labeling field
With printing: no
Mounting type: flush-mounted
Material: plastic
Material quality: thermoplastic
Halogen-free: yes
Surface protection: untreated
Surface finish: glossy
Color: white
RAL number (similar): 9010
Transparent: no
Mounting type: screw mounting
With sockets/couplings: no
With strain relief: no
Shielded sockets: no
Shielded housing: no
Terminal block: no
Suitable for protection class (IP): IP20
Device width: 73 mm
Device height: 73 mm
Device depth: 50 mm

Merten Angled Outlet pws/gl 464919: additional details
For data connection and communication technology. Please order the corresponding inserts separately. Note: The installation of the angled outlet on the 1-M or ATELIER-M frames is not visually appealing. The M-SMART or M-PLAN frames should be used instead.

Scope of delivery: Without inserts.
Material: Brilliant thermoplastic.
Color: Polar white glossy.
EAN: 4042811034016.
