MDT Glass button

MDT Technologies Glass Switch Plus 8-fold BE-GT08S.01

Manufacturer: MDT Technologies
Designation: Glass Switch Plus 8-fold black
Type: BE-GT08S.01
Bus system KNX: yes
Bus system KNX wireless: no
Bus system wireless bus: no
Bus system LON: no
Bus system Powernet: no
Other bus systems: none
Bidirectional wireless: no
Mounting type: flush-mounted
With theft/dismantling protection: no
With bus coupling: yes
Number of activation points: 8
Number of buttons: 8
Power consumption: 0.3 W
With LED display: yes
With labeling field: yes
With display: no
Material: glass
Material quality: other
Surface protection: other
Surface finish: glossy
Color: black
Transparent: no
With room thermostat: no
With infrared sensor: no
Protection class (IP): IP20
Minimum depth of device box: 35 mm

MDT Technologies Glass Switch Plus 8-fold BE-GT08S.01: additional details
KNX Glass Switch Plus 8-fold, black. Version with 8 sensor surfaces and LEDs for operational and status indication. The buttons can be freely configured as button pairs or individual buttons. Values can be sent, forced control and switching commands can be configured. Short and long button presses with 2 objects. Surrounding orientation light. White and red LED per sensor surface. LED brightness adjustable in 5 levels via day and night object. Single and double button operation for dimmer and blind functions. Labeling film to be inserted under the glass surface. Installation in switch box, delivery includes labeling film. Dimensions (H x W): 163 x 92 mm. Integrated bus coupler.
