Scope of delivery:
Product features:
The tool is designed for hammer drilling and drilling in brick, concrete, and stone. It is also suitable for normal drilling in wood, metal, ceramics, and plastic. The cordless hammer drill impresses with its high performance despite its compact size. The device comes with a carbon brushless motor, which works more efficiently than a conventional motor and is virtually wear-free. The housing of the device has been designed to absorb the vibration of the percussion mechanism, ensuring comfortable working. The rotary hammer has a clutch that switches off silently, and the motor allows a high speed for fast work progress. Handling is optimized by the handle with depth stop and the rubberized handle, guaranteeing a secure grip at all times.
Technical data:
Voltage: 18 V
Impact energy: 1.20 joules
Tool holder: SDS plus
Motor type: brushless
Max. no-load speed: 0-680 rpm
Max. impact speed: 4,800 rpm
Drill diameter concrete: Ø 17 mm
Drill diameter wood: Ø 13 mm
Drill diameter steel: Ø 10 mm
Weight without battery: 1700 g
Sound pressure level: 86 dB(A)
Sound power level: 97 dB(A)
Measurement uncertainty (K): 3 dB(A)
For commercial use, please observe the building regulations!.
Drilling machine + percussion drilling machine Type | Impact drill |
Weight | 1.70 kg |
Tool holder | SDS-plus |
Battery voltage | 18 V |
Battery system | Makita LXT 18V |
Item number | 47799042 |
Manufacturer | Makita |
Category | Drills + Cordless screwdriver |
Manufacturer no. | DHR171SM1X3 |
Release date | 13.8.2024 |
Colour | Blue |
Exact colour description | Blue |
Drilling machine + percussion drilling machine Type | Impact drill |
Use | Drilling |
Tool holder | SDS-plus |
Additional functions | Brushless electric motor |
Max. drilling diameter in wood | 13 mm |
Max. drilling diameter in steel | 10 mm |
Max. drilling diameter in concrete | 17 mm |
Power supply | Rechargeable battery operated |
Battery type | Lithium |
Battery voltage | 18 V |
Capacity | 4 Ah |
Number of batteries | 1 x |
Battery system | Makita LXT 18V |
Battery equipment | 1 battery supplied |
Charger equipment | Charger supplied |
Idle speed 1st gear | 680 rpm |
Max. Idle speed | 680 rpm |
Max. Number of strokes | 4800 rpm |
Impact energy | 1.20 J |
Sound power level (LWA) | 97 dB |
Sound pressure level (LpA) | 86 dB |
Max. noise level | 97 dB |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Metal drills | 3 mm, 3.5 mm, 4 mm, 4.5 mm, 5 mm, 5.5 mm, 6 mm, 6.5 mm |
Drills | 10 mm, 12 mm |
Items per sales unit | 1 x |
Drill + cordless screwdriver equipment | Drill depth stop, Transport case |
Weight | 1.70 kg |
