Lapp Cable gland

Lapp accessories cable gland ST-M12x1.5 R7035 LGY

Manufacturer: Lapp Zubehör
Designation: Cable gland SKINTOP
Type: ST-M12x1.5 R7035 LGY
Thread type: Metric
Nominal thread size metric/PG: 12
Thread pitch: 1.5 mm
Thread length: 8 mm
Width across flats: 15 mm
Hexagon square dimension: 0 mm
Suitable for cable diameter: 3.5...7 mm
Material: Plastic
Material grade: Polyamide (PA)
Surface protection: Untreated
Halogen-free: No
Glass fiber reinforced: No
Protection class (IP): IP68
Impact resistant: No
Color: Gray
RAL number: 7035
Bending protection: No
With locknut: No
Engaging in opening: No
Design: Straight
Multiple sealing insert: No
Flat cable gland: No
With strain relief: No
Type of seal: Sealing ring
Separable gland: No
Operating temperature: -40..100 °C
Explosion-proof design: No
For Ex-zone gas: None
For Ex-zone dust: None
For armored cables: No
EMC design: No
Shielded: No

Lapp accessories cable gland ST-M12x1.5 R7035 LGY is ideal for applications where multiple cables and lines need to be inserted into a housing in a space-saving manner. It is suitable for machine and apparatus engineering, photovoltaics, automation technology, offshore plants, and shipbuilding. The cable gland offers increased oil resistance for higher functional safety and a variety of accessories, such as multiple sealing inserts. It also provides permanent vibration protection, optimal strain relief, and large, variable clamping ranges. The metric connection thread complies with DIN EN 60423 and serves as a basis for technical specifications according to DIN IEC 62444.
