JUNG Channel SCHUKO socket

Jung Kanal-Schuko socket outlet AS 1522 BF WW

Manufacturer: Jung
Designation: Kanal-Schuko socket outlet 2-fold
Rated current: 16 A
Rated voltage: 250 V
Type: AS 1522 BF WW
Design: Schuko
Protective contact: Yes
Protective conductor contact round: Yes
Number of active contacts (round): 2
With signal lamp: No
With built-in USB power supply: No
Number of units: 2
Number of phases: 1
Imprint/marking: Without
Connection type: Plug-in terminal
With hinged cover: No
With increased touch protection: No
Text field/inscription area: No
Color: White
RAL number (similar): 9016
Transparent: No
Lockable: No
Eject mechanism: No
With function lighting: No
With orientation light: No
Overvoltage protection: No
Residual current protection: No
With microfuse: No
Special power supply: Without special power supply
Mounting type: Flush mounting
Mounting type: Mounting with screw
Material: Plastic
Material grade: Thermoplastic
Halogen-free: Yes
Surface protection: Other
Finish: Glossy
Antibacterial treatment: No
With on/off switch: No
With loop-through function: No
Rotated central insert: No
Suitable for protection class (IP): IP20
Device width: 151.5 mm
Device height: 80.5 mm
Cover: Complete housing

Further details: Wired with spring terminals for rigid and untreated flexible conductors up to 2.5 mm². Connection terminals to DIN VDE 0620 with molded frame for use in commercially available trunking boxes. Support ring is integrated into the protective measure via an earthing rail. Version with labeling field available on request.

Dimensions: 80.5 x 151.5 mm
Material: Thermoplastic
EAN: 4011377161221.
