Janitza B23 313-10J three-phase meter

Ratings
BrandMore from Janitza
Currently out of stock
Free shipping starting at 50.–

Product details

Type B23 313-10J for DIN rail mounting, 4TE, tariffs with integrated M-Bus interface. 2x inputs for controlling tariffs or counting external pulses. 2x outputs optionally as pulse output for active or reactive energy or as alarm output. Pulse duration: 10-990 ms. Measurement accuracy for active energy: Class 1. Measurement accuracy for reactive energy: Class without MID. Connection cross-section for measurement: 25 mm². Current measurement range: 0.25 to 65 A. Voltage range: 3x 220-240 AC, -20% to -15%. Frequency: 50-60 Hz. Temperature range: -40 to 70 degrees Celsius. No reset of energy meter readings. The meter is calibrated according to MID and approved according to IEC B23 313-10J.

Key specifications

measurement module
Amp
Energy meter type
Energy meter
Mounting type
Top-hat rail
Nominal voltage
400 V
Maximum current
65 A

General information

Item number
45547994
Manufacturer
Janitza
Category
Energy monitors
Manufacturer no.
1401358
Release date
7.5.2024

Energy meter property

Energy meter type
Energy meter
Functionalities
Alarm
Mounting type
Top-hat rail
measurement module
Amp
Maximum current
65 A
Nominal voltage
400 V
Display type
Digital
Tariff execution
Second tariff
Pulse output
Electrical
Polar type
Three-wire

Origin

Country of origin
Italy
