Helios Miniature fan HR90 KE
7 pieces in stock
Max. Air flow rate2
Product details
Helios Fans Mini Fan HR 90 KE
Manufacturer: Helios Fans
Description: Mini fan with ball bearings
Type: HR 90 KE
Mains frequency: 50 Hz
Rated voltage: 230 V
Installation type: Surface-mounted
Housing material: Plastic
Color: White
Airflow: 80 m³/h
Protection class (IP): IP45
Nominal diameter: 100 mm
Configuration: Standard
Design: Axial
Direction: Supply and exhaust ventilation
Additional details:
Small fan with ball bearings, splash-proof plastic housing (IP 45) with grille cover. The upward-facing slats completely prevent visibility into the intake opening and the built-in pre-rotor. Snap-fit mounting for tool-free installation in ducts with a nominal diameter of 100 mm. Touch protection according to DIN EN 294. Impeller with 5 profiled blades made of plastic, high efficiency. AC split-pole motor with thermal overload protection for continuous operation with maintenance-free, permanently lubricated ball bearings, non-reversible.
Ventilation fan type | Axial fan |
Max. Air flow rate | 80 m³/h |
Suitable for pipe diameter | 100 mm |
Power consumption | 17 W |
Item number | 10851791 |
Manufacturer | Helios |
Category | Ventilation fan |
Manufacturer No. | HR90KE |
Release date | 25.3.2019 |
Sales rank in Category Ventilation fan | 7 of 2598 |
Colour | White |
Exact colour description | White |
Material group | Plastic |
Material | Plastic |
Ventilation fan type | Axial fan |
Max. Air flow rate | 80 m³/h |
Suitable for pipe diameter | 100 mm |
Power supply | Electrical connection |
Power consumption | 17 W |
Country of origin | Germany |
CO₂ emissions | 2.08 kg |
Climate contribution | CHF 0.11 |
Length | 14 cm |
Width | 14 cm |
Height | 14 cm |
Weight | 600 g |
Length | 14.50 cm |
Width | 10 cm |
Height | 14 cm |
Weight | 668 g |
