Hager Switch-disconnector

Hager switch-disconnector HAC308
Manufacturer: Hager
Designation: Switch-disconnector 3P 80A
Type: HAC308
Version as main switch: Yes
Version as maintenance/repair switch: Yes
Version as safety switch: Yes
Version as emergency stop device: No
Version as reversing switch: No
Number of switches: 1
Max. rated operational voltage Ue at AC: 415 V
Rated operational voltage: 380...415 V
Rated uninterrupted current Iu: 80 A
Rated uninterrupted current at AC-23, 400 V: 80 A
Rated uninterrupted current at AC-21, 400 V: 80 A
Rated short-time withstand current Icw: 1.5 kA
Rated breaking capacity at AC-23, 400 V: 36 kW
Breaking capacity at 400 V: 52 kW
Rated short-circuit current Iq: 50 kA
Number of poles: 3
Motor drive optional: No
Motor drive integrated: No
Voltage release optional: No
Type of device: Built-in device
Fixed installation technology
Suitable for floor mounting: Yes
Suitable for front mounting 4-hole: No
Suitable for front mounting central: No
Suitable for distribution mounting: Yes
Suitable for intermediate: No
Colour of actuating element: Grey
Design of actuating element: Short rotary handle
Lockable: Yes
Connection type main circuit: Screw connection
Protection class (IP), front: IP20
Protection class (NEMA): Other

Hager switch-disconnector HAC308: Further details
Switch-disconnector 3 pole 80A for top hat rail or mounting plate. Switch-disconnector for mounting on top-hat rail or mounting plate, rotary actuator can be locked directly on the device in the OFF state with a padlock. Ensures switching on and off under load and a safety disconnecting function in all low-voltage circuits.
