Hager Surge arrester T2 4P SPB415 40kA TT/TNS Defect indication+contact

Hager Surge Arrester SPB415

Manufacturer: Hager
Designation: Surge Arrester
Type: SPB415
DC Network Form: no
IT Network Form: no
TN Network Form: yes
TN-C Network Form: no
TN-C-S Network Form: yes
TN-S Network Form: yes
TT Network Form: yes
Other Network Forms: no
Number of Conductors (without Ground): 4
Nominal Surge Current (8/20): 20 kA
Maximum Surge Current (8/20): 40 kA
Nominal Voltage AC: 400 V
Maximum Continuous Voltage AC: 275 V
Maximum PV Voltage: 0 V
Protection Level: 1.35 kV
Protection Level L-N: 1.35 kV
Protection Level N-PE: 1.6 kV
Maximum Overcurrent Protection Device for Stub Wiring (Fuse): 125 A
Maximum Overcurrent Protection Device for V-Wiring (Fuse): 80 A
Short-Circuit Strength (Isccr): 25 kA
Integrated Short-Circuit Protection: no
Integrated Selective Short-Circuit Protection for gG Fuse: 120 A
Integrated Pre-Fuse: no
Leakage Current Free: no
Mounting Type: TH35 Rail
Size: 4 TE
Maximum Conductor Cross-Section Solid (Single/Multi-Wire): 35 mm²
Maximum Conductor Cross-Section Flexible (Fine-Wire): 25 mm²
With Remote Signaling Contact: yes
Device Signaling: optical
Test Class Type 2: yes
Protection Class (IP): IP20

Hager Surge Arrester SPB415: additional details
Surge arrester T2 4P 40kA TT/TNS fault indication + contact. Type 2 surge arrester in a 3+1 configuration, designed to protect three-phase TT and TN-S systems. Comprising a fourfold base element, three protective plugs with temperature-monitored high-performance varistors, and one plug as a total current spark gap with dynamic disconnection device. Optical fault indication on the plugs in case of overload. Changeover contact for remote fault indication. Connections for the active conductors from below, for ground/PE and remote signaling contact from above. Biconnect terminals for connecting round conductors and wiring bridges. Labeling option on the base element.
