Grohe Infrarot-Elektronik TECTRON SKATE

GROHE Tectron Rondo infrared electronics for urinals feature an infrared sensor for bidirectional communication. It is powered by a 6 V lithium battery, type CR-P2, with a battery life of approximately 7 years based on 150 activations per day. The product has a GROHE Long-Life surface, metal housing, and is surface-mounted. It operates with a minimum flow pressure of 0.5 bar and a maximum operating pressure of 10 bar with pre-shutoff. The flush pipe includes an internal connector, a multi-stage battery status indicator, 7 preset programs, automatic flushing, cleaning mode, and pre-flush. Additional functions and settings can be accessed with remote control 36 407. The flush time is adjustable, either manually or with remote control. It also carries a CE mark.

Additional technical specifications:

• Inlet connection: external thread
• Supply connection size: 1/2 inch
• Connection voltage: 6V
• Type of power supply: battery
• Type of control: infrared
• Automatic flush cycle: yes
• Transport category: 2
• Sensor detection range: 45mm
• Adjustable flow capacity: yes
• Hazard class: 9
• Base color: chrome
• Height: 178mm
• With transformer: no
• With pre-flush: yes
• With intermediate flush: yes
• Official designation: lithium metal battery
• Programmable with remote control: yes
• Technical designation: manganese dioxide lithium battery
• Flow rate class: none
• Pre-pressure: 1 bar
• Wall distance: 45mm.
