Gesipa Blind rivets aluminium/steel 4.8x17 mm PolyGrip Mini-Pack with 50 pieces

Save CHF3.30
Delivered between Sat, 26.9. and Fri, 2.10.
More than 10 pieces in stock at supplier
Free shipping starting at 50.–

Diameter2

Length2

Product details

GESIPA-PolyGrip is the favorite for challenging and demanding applications in industrial environments for all types of materials. Originally developed as a multi-range blind rivet, the GESIPA-PolyGrip has evolved over time to acquire many additional talents, making it a preferred choice for meeting challenging applications. Whether in aluminum, steel, or stainless steel, indoors or outdoors, with hard or soft joining materials, critical hole diameters, and tolerances: when no one else can manage, the GESIPA-PolyGrip is almost always the saving solution.

Key features:

  • Wide clamping range: A single PolyGrip blind rivet can replace up to five different sizes of DIN standard blind rivets. This results in the following benefits for you:
  • Limitation of types
  • Reduction of variety in stock
  • Decrease in the risk of confusion, leading to fewer processing errors

Excellent hole friction: The rivet shank deforms radially during the setting process, compensating for drilling inaccuracies, misalignment, and diameter differences to create a play-free and tight connection.

Secure remaining mandrel locking: PolyGrip blind rivets do not produce rattling noises from released mandrels, nor is there a risk of mandrel loss. Under certain conditions, PolyGrip blind rivets are also splash-proof. With their good hole friction properties and remaining mandrel locking, they offer an economical alternative to closed blind rivets. When it comes to preventing water from penetrating through the connection, PolyGrip blind rivets are an ideal choice. The broad head formation ensures high tensile strength values and thus a high level of safety.

Key specifications

Rivet type
Blind rivets
Length
17 mm
Diameter
4.80 mm

General information

Item number
22850723
Manufacturer
Gesipa
Category
Rivets
Manufacturer No.
53197450
Release date
26.10.2022
External links

Colour

Colour
Silver
Exact colour description
AluminiumSteel

Material

Material group
Metal
Material
AluminiumSteel
surface finish
Galvanized

Rivet features

Rivet type
Blind rivets
Shear force
1500 N

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
5.52 kg
Climate contribution
CHF 0.13

Scope of delivery

Items per sales unit
50 pcs.

Product dimensions

Length
17 mm
Diameter
4.80 mm
Weight
170 g
