Gedore Torque spanner 8572-01 1 1/2 ″ 1500 - 3000 Nm

1/2", 1500 Nm, 3000 Nm
Delivered between Fri, 30.5. and Tue, 17.6.
Only 2 items in stock at supplier

Product details

All-metal construction of high-strength aluminium alloy with fixed square drive and aluminium handle, designed for right-handed use. It features a combined double scale in N.m/Ibf.ft. The housing is made of light alloy, while stressed parts are crafted from special steel. An audible and perceptible trigger signal is included, along with quick setting by an ergonomic adjustment knob. The tool is adjusted to a trigger accuracy of ± 3% tolerance of the set scale value, ensuring no value shifts or influence on accuracy due to two-handed working or confirmations outside the handle, as both the square drive and the pivot point are aligned in one axis, providing high application safety. The tool can be extended to reduce workload and is available in several versions: 1. Standard (with square drive) 2. With extension tube 3. With extension tube and double square drive 4. With double square drive 5. With 2 extension tubes. Further technical features include packaging in a cardboard box and subject to inspection with a test certificate according to DIN EN ISO 6789-2-2017. Operating instructions are included with delivery in a cardboard box.

Key specifications

Torque wrench Version
Single square
Item number
22170417

General information

Manufacturer
Gedore
Category
Torque wrenches
Manufacturer no.
7717160
Release date
13.9.2022

Material

Material group
Metal
Material
Aluminium alloy

Torque Wrench Features

Torque wrench Version
Single square
Max. torque
3000 Nm
Min. torque
1500 Nm
Inch Size
1/2"
Tightening direction
Clockwise rotation

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
1 piece

Product dimensions

Length
1037 mm
Width
70 mm
Height
40 mm
Weight
15000 g
