Fronius Primo GEN24 4.0 Plus

Fronius hybrid inverter Primo GEN24 4.0 Plus Manufacturer :Fronius Designation :Hybrid inverter 4000VA Type :Primo GEN24 4.0 Plus Rated voltage MPP :65...530 V Rated output power AC :4000 W Number of independent MPPT inputs :2 European efficiency :97.1 % With transformer :no With data logger :yes Display :without Ethernet :yes Wireless :yes Built-in battery :no Backup power capability :yes Suitable for outdoor installation :yes Protection class (IP) :IP66 Weight :16.6 kg Width :474 mm Height :528 mm Depth :163 mm Fronius hybrid inverter Primo GEN24 4.0 Plus: further details The Fronius Primo GEN24 Plus is the ideal hybrid inverter for private households. With many standard features, the single-phase device covers all customer requirements. Standard connection to WLAN, Ethernet, emergency power function - with the integrated PV Point (basic emergency power supply for a socket) and full backup option with battery connection/ Energy management - 4 digital IOs to increase self-consumption, Multi Flow Technology - parallel energy flows, even in the event of an emergency, Dynamic Peak Manager - best yields even in shaded areas, SuperFlex Design - maximum freedom in PV system design, Solar.web - Evaluation and analysis tool for greater transparency, Wide range of open interfaces Simple integration of third-party components, Active Cooling Technology - Long service life of the inverter. Max. PV generator output 6 kWpeak Battery connection: max. input/output power 4140 W, max. AC charging power 4000 W, Compatible batteries: BYD Battery-Box Premium HVS/HVM, Interfaces: WLAN, 2x Ethernet LAN, 6 digital inputs/outputs + 6 digital inputs for connection to ripple control receivers, energy management emergency shutdown (WSD) 2x RS485 for Modbus RTU SunSpec (third-party provider), Fronius Smart Meter, battery, Fronius Ohmpilot , EAN: 9007947330598
