Elmag - Sägeblatt HSS / DMo5 / TiN Beschichtet TiN 225x2,0x32mm T3 220 Zähne

Elmag - HSS Saw Blade / DMo5 / TiN Coated TiN 225x2.0x32mm T3 220 Teeth

Circular saw blades - HSS/DMo5 with TiN coating. To increase the service life of the saw blades, we have equipped our products with a special TiN coating. This process also preserves the surface grinding of the coated area with a surface roughness of 0.3 Rz, a washing process with chemical activation, and vacuum drying to ensure the area is thoroughly cleaned and to prevent oxidation and moisture. Additionally, side runout and straightness are checked and corrected.

The hard coating, with a thickness of 3 microns, is based on titanium and is produced at a process temperature of approximately 490°C. This hard coating has a friction value of 0.47 and an oxidation temperature of 640°C. The coating hardness is 2,480 Vickers (HV 0.05). The low thermal conductivity of this hard coating provides good thermal protection for the body.

In terms of application, it is particularly suitable for machining structural steel and should always be supplied with ample coolant lubrication. However, this hard coating is not suitable for machining copper, brass, and bronze.

Technical Data:
Blade Diameter: 225mm
Bore: 32mm
Tooth Pitch: T3
Number of Teeth: 220.
