Eaton NZMC1-A63 Circuit-breaker 271394 3p 63A 271394
Product details
Eaton circuit-breaker NZMC1-A63 Manufacturer :Eaton Designation :Circuit-breaker 3p 63A Type :NZMC1-A63 Rated continuous current Iu :63 A Rated voltage :690 V Rated short-circuit breaking current Icu at 400 V, 50 Hz :36 kA Overload release Current setting :50..63 A Setting range of the short-time delayed short-circuit release :0 A Setting range of the instantaneous short-circuit release :380...630 A Integrated earth fault protection :no Connection type main circuit :frame terminal Device type :built-in device Fixed mounting technology Suitable for top-hat rail mounting :no Top-hat rail mounting optional :yes With trip indicator :no With integrated undervoltage release :no Number of poles :3 Position of connection for main circuit :front Design of operating element :toggle lever Complete device with protection unit :yes Motor operator integrated :no Motor operator optional :no Protection class (IP) :IP20 Eaton circuit-breaker NZMC1-A63: further details Circuit-breaker NZM1, 3-pole, Breaking capacity 400/415 V 50 Hz( Icu ): 36 kA, Rated current = Rated uninterrupted current Rated current = Rated uninterrupted current( In = Iu ): 63 A, Installation technology: Fixed installation, Frame terminal, Standard/approval: IEC, Protective function: System and cable protection , EAN: 4015082713942.
