Eaton NZM1-XAL12AC/DC
Product details
Eaton shunt opening release NZM1-XAL12AC/DC
Manufacturer: Eaton
Designation: Shunt opening release o.s.l. Kl.NZM1-XAL12AC/DC
Rated control supply voltage Us at AC 50 Hz: 12 V
Rated control supply voltage Us at AC 60 Hz: 12 V
Rated control supply voltage Us at DC: 12 V
Type of voltage for operation: AC
Initial value of instantaneous short-circuit release setting range: 0 A
Final value of instantaneous short-circuit release setting range: 0 A
Electrical connection type: Screw connection
Suitable for circuit-breakers: No
Suitable for load-break switches: Yes
Suitable for motor-protective circuit-breakers: No
Suitable for overload relays: No
Eaton shunt release NZM1-XAL12AC/DC: further details
Optional accessories for the NZM circuit-breaker series offer a comprehensive portfolio of application possibilities for worldwide use. Mounting is flexible and simple thanks to modular function groups.
Notes: The circuit-breakers trip when a voltage pulse occurs or when a continuous voltage is applied. If the shunt release is live, contact with the main switch contacts is safely prevented during closing attempts. The shunt opening release cannot be installed at the same time as leading auxiliary contact NZM..-XHIV.. or undervoltage release NZM..-XU....
Suitable for: NZM1(-4), N(S)1(-4)
EAN: 4015082597344.
