Eaton Circuit breaker type D 40A 3 pole

Ratings
BrandMore from Eaton
Delivered between Sat, 2.8. and Wed, 20.8.

Product details

Range = xPole
Series = PXL, S200
Number of poles = 3
Rated current = 40 A
Tripping characteristic = Type D
AC rated voltage = 400 V
DC rated voltage = 48V
Breaking capacity = 10 kA
Length = 52.5mm
width = 80mm
Depth = 60mm

IEC / EN 60898. PXL series, D-characteristic, 3-pole. Circuit breaker with high selectivity for pre-fusing due to low let-through energies Displacement compatible With double convenience terminal Lift/Maul above and below Free choice of top and bottom rail arrangement Finger / back of hand safe Quick mounting with 3 detent positions for DIN rail IEC/EN 60715.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
52.50 mm
Width
80 mm
mounting style
Flush-mounted
number of poles
3
Item number
9717421

General information

Manufacturer
Eaton
Category
Residual-current device
Manufacturer no.
236469
Release date
24.9.2018

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Flush-mounted
number of poles
3
Tripping characteristic
D
Rated current
40 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
440 V
Protection type (IP code)
IP20

Origin

Country of origin
Romania

Sustainability

Manufacturer commitment
SBTi

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
52.50 mm
Width
80 mm
