Dehn SOEHNE Combination arrestor valve TNC 255
Delivered between Wed, 29.10. and Sat, 8.11.
free shipping
Product details
Multipole DEHNventil modular combination arrester, type 1 + type 2 according to EN 61643-11 on spark gap basis, consisting of base part and plug-in protection modules. Highest system availability due to RADAX flow follow current limitation. Enables end device protection. For protecting low-voltage consumer equipment against surges, even in the event of direct lightning strikes. Can be used according to the lightning protection zone concept at interfaces 0A-2.
Surge protection type | Combination arrester |
Number of conductors | 3 x |
Test class | Type 1 |
Mounting type | Top-hat rail |
Item number | 12919504 |
Manufacturer | Dehn |
Category | Surge protection |
Manufacturer no. | 951305 |
Release date | 14.3.2020 |
Sales rank in Category Surge protection | 11 of 2774 |
External links |
Surge protection type | Combination arrester |
Number of conductors | 3 x |
Lightning impulse current | 75 kA |
Rated leakage surge current | 50 kA |
Nominal voltage | 230 V |
Protection level | 1.50 V |
Mounting type | Top-hat rail |
Test class | Type 1 |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 0.01 m |
Width | 0.01 m |
Height | 0.01 m |
