Caleffi Diaphragm safety valve 1/2inch, 6 bar
More than 10 pieces in stock at supplier
Product details
The Caleffi membrane safety valve is a reliable safety device specifically designed for potable water applications. With a connection size of 1/2 inch and a maximum operating pressure of 6 bar, this valve provides an effective solution to prevent pressure surges in closed hot water systems. It meets the requirements of TRD 702 as well as DIN 4753 and DIN 1988, making it a safe choice for use in various sanitary applications. The valve is made of robust brass and features a plastic spring cover that contributes to the product's durability and reliability. The temperature range of 5 to 95 degrees Celsius allows for versatile applications in different environments. The factory settings for the activation pressure are configured at 4, 6, 8, and 10 bar, enabling adjustments to specific requirements.
- Used as a safety device against pressure surges
- Corner design with venting device
- Made from high-quality brass
- Spring cover made of durable plastic
- Temperature range of 5 to 95 degrees Celsius.
Material | Brass |
Connection thread | 1/2" |
Sanitary valve type | Boiler valve |
Diameter | 50.80 mm |
Item number | 22563439 |
Manufacturer | Caleffi |
Category | Valve |
Manufacturer no. | 531460 |
Release date | 3.10.2022 |
Sales rank in Category Valve | 23 of 2361 |
Colour | Black |
Material | Brass |
Material group | Metal |
Sanitary valve type | Boiler valve |
Connection thread | 1/2" |
Max. Operating pressure | 6 bar |
Country of origin | Germany, Italy |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1x |
Width | 50 mm |
Diameter | 50.80 mm |
Height | 35 mm |
Weight | 185 g |
Length | 7.80 cm |
Width | 5.10 cm |
Height | 4.80 cm |
Weight | 180 g |
