BKS Panic frame mortise lock B 1316 E DIN right 24/245/45/92/9 mm angular

The panic frame insert lock B 1316 E from BKS is a reliable solution for single-leaf doors that offers both security and functionality. It is specifically designed for use in fire protection doors and meets the requirements of DIN 18251-2 Class 3 as well as EN 12209. This lock is also approved for emergency exits (EN 179) and panic doors (EN 1125), making it an ideal choice for public buildings and facilities. The construction includes a latch made of precision casting and a bolt made of zinc die-casting, ensuring high stability and durability. With a bolt throw of 20 mm and a distance of 92 mm, the lock provides an effective security solution. The profile width of 24 mm and the angled design allow for seamless integration into the door. The lock is equipped with a reversible function, offering additional flexibility in use.

• Fire protection approved according to DIN 18251-2 Class 3 and EN 12209
• Suitable for emergency exits (EN 179) and panic doors (EN 1125)
• Latch made of precision casting and bolt made of zinc die-casting
• Backset measurement of 15 mm and lock case closed at the top and bottom
• Stainless steel profile with a profile length of 245 mm.
