Baco Push button Red Flush illuminated

Series: Baco
Cut-out diameter: 22 mm
Push button color: Red
Push button shape: Round
Push button actuation: Spring return
Push button type: Illuminated, flush
Push button material: Plastic
Protection class: IP66

Use an LED module to illuminate the push buttons. For suitable contact blocks, see the corresponding order numbers. The mounting clip is essential for the installation of contact blocks and LED modules. Push button heads with spring return are available as separate units for maximum flexibility in numerous possible solutions. The push button heads feature an integrated anti-rotation mechanism that can be retracted when not needed. The insulating material of the head ensures electrical safety, and the push button is clearly visible and ergonomically designed. Cut-out diameter 22 mm, spring return, flush for use with a clip and electrical contact blocks. Chrome-plated plastic bezel with locking ring, protection class IP66 against ingress of water.
