Sonel Power quality analyser PQM-702

The PQM-702 power quality analyzer from Sonel has been developed for high-level power quality analysis. It complies with all common EU and IEC standards, and all measurements are conducted according to IEC 61000-4-30 Class A. Using current clamps, currents of up to 3 kA can be measured, and along with all other parameters captured by the analyzer, they can be transmitted to a PC via WLAN, integrated modem (UTMS or GSM), USB, or microSD card using the included software for professional evaluation and analysis. Reports can be automatically generated according to EN 50160. The precise network analysis is further supported by the integrated GPS receiver for time synchronization of the RTC. Installation is possible both indoors and outdoors.
