Best selling Relays from Jumo
This page always stays fresh and updates automatically.
1. Jumo Thyristor power controller
Jumo Thyristor Power Controller 00543455
Manufacturer: Jumo
Designation: Thyristor Power Controller 100A, 400V, P-Control
Type: 00543455
Rated Control Supply Voltage Us at AC 50 Hz: 320..460 V
Operating Voltage: 320..460 V
Rated Operating Current Ie at AC-1: 100 A
Rated Operating Current Ie at AC-51: 100 A
Number of Phases: 1
Suitable for Rail Mounting: Yes
Zero-Cross Switching: No
The single-phase thyristor power controller in savings mode operates in pulse group operation with subordinate P-control and configurable partial load break monitoring. The device displays all process and configuration parameters clearly on an LC display and is easy to operate via 4 front buttons. Process errors are reported by a fault relay. Process values can be output to an analog output. Areas of application include any situation where larger resistive and inductive loads need to be switched, such as in industrial furnace construction and plastic processing.
2. Jumo 702113/8-0000-25/000
The compact controller is part of a series of controllers that can be used universally and in various DIN formats for regulating temperature, pressure, or, for example, flow. It is suitable for front mounting. The controllers are characterized by a simple, clearly structured operation supported by text. Process values and parameters are displayed through two 18-segment LCD displays. In addition, the model features individual display elements for the switching positions of the outputs, as well as for manual operation, ramp function, and timer. The controller also includes a self-optimization function and a program controller. The limit monitoring function, digital control signals, and a service counter complete the capabilities of the controller. With the help of the setup program (including program editor and ST editor), the controller can be conveniently configured with a PC. During configuration via the USB interface, no separate power supply is required (USB-powered). Operation is carried out via a membrane keyboard with four buttons and can also be used in harsh environmental conditions due to the high protection class IP65. Depending on the hardware version, the device can be used as a two-point controller, three-point controller, three-point step controller, or continuous controller. The PID controller has a universal input, two relay outputs (normally open), one digital input, and one digital input/output. The power supply range is AC/DC 20 to 30 V, 48 to 63 Hz.
3. Jumo 434642
Jumo Microprocessor Controller 00434642
Manufacturer: Jumo
Designation: Microprocessor Controller 1 Relay (Changeover)
Type: 00434642
Electrical connection type: Screw connection
Rated control supply voltage Us at AC 50 Hz: 110..240 V
Voltage type for actuation: DC
With removable terminals: no
Number of measurement circuits: 1
Error storage possible: no
External reset possible: no
Number of contacts as changeover: 1
Temperature measurement range: -200..850 °C
Width: 22.5 mm
Height: 109 mm
Depth: 124.8 mm
The PID controller has a relay output (changeover). The power supply is AC 110 to 240 V +10/-15 %, 48 to 63 Hz. It is a universal, freely programmable microprocessor controller suitable for a wide range of control applications. At the freely configurable measurement input, resistance thermometers, thermocouples, as well as current and voltage signals can be connected. The linearizations of common sensors are stored. A 2-line alphanumeric LCD display is available for displaying the actual and set values or for dialog guidance. The parameter setting is dynamic, and after two seconds, the value is automatically adopted. The standard self-optimization feature determines optimal control parameters at the push of a button. Additionally, a ramp function with adjustable gradient and a timer function are included. The compact controller can also be used as a two-point controller with limit monitoring. It is mounted on a DIN rail and wired via screw terminals with a maximum wire cross-section of 2.5 mm². It has the approvals cULus, GOST, CSA.
4. Jumo 1Ph. power controller
Jumo 1-Phase Power Controller 00556184
Manufacturer: Jumo
Designation: 1-Phase Power Controller
Type: 00556184
Rated control supply voltage Us at AC 50 Hz: 184..264 V
Voltage type for operation: AC
Operating voltage: 184..264 V
Rated operational current Ie at AC-1: 20 A
Rated operational current Ie at AC-3: 0 A
Rated operational current Ie at AC-51: 20 A
Rated operational current Ie at AC-53a: 0 A
Rated operational current Ie at AC-53b: 0 A
Number of phases: 1
Suitable for panel mounting: yes
Zero-cross switching: no
The single-phase thyristor power controller operates in pulse group mode with underlying P-control and configurable partial load break monitoring. The device displays all process and configuration parameters clearly on an LC display and is easy to operate using 4 front buttons. Process errors are reported by a fault relay. Process values can be output to an analog output. Applications are found wherever larger resistive and inductive loads need to be switched, such as in industrial furnace construction and plastic processing.
