Weidmüller Main cable terminal 18One gr touch-proof 1562160000

Weidmüller Main Distribution Terminal WPD 304 #1562160000

Manufacturer: Weidmüller
Designation: Main Distribution Terminal 3X25/6X16+9X10 3XGY
Type: WPD 304 #1562160000
Rated Current In: 164 A
Rated Voltage: 1000 V
Electrical Connection Type 1: Screw Connection
Number of Levels: 1
Number of Connection Points per Level: 6
Mounting Type: Direct Mounting
Material of Insulating Body: Thermoplastic
Operating Temperature: -50..130 °C
Flammability Class of Insulating Material according to UL 94: V0
Width: 94.5 mm
Height: 68 mm
Depth: 49 mm
End Plate Required: No
Color: Gray
Internally Bridged Levels: Yes

Weidmüller Main Distribution Terminal WPD 304 #1562160000: additional details Terminal block for potential distribution. With high contact density. EAN: 4050118385243.
