Telegärtner Patchk.S/FTP

S/FTP, CAT6a, 1 m
CHF22.70/1m
Ratings
BrandMore from Telegärtner
Delivered between Sat, 22.11. and Wed, 10.12.
Free shipping starting at 50.–

Product details

Telegärtner Patch Cable S/FTP Cat.6A 100017307

Manufacturer: Telegärtner
Description: Patch Cable S/FTP Cat.6A green
Length: 1 m
Connector type connection 1: RJ45 8(8)
Connector type connection 2: RJ45 8(8)
Sheath color: green
Bend protection sleeve: molded
Latch lever protection: yes
Color of bend protection sleeve: black
Cable construction: 4x2
AWG cross-section: 26
Pin assignment: 1:1

The industry's requirements for secure and continuous transmission of ever-increasing data volumes necessitate cabling solutions that can withstand current and future demands. To meet these growing requirements, Telegärtner is continuously working on the development of new products and the enhancement of its existing product portfolio.

The UL-listed raw cable used for the assemblies complies with the S/FTP 4x2xAWG26/7 Cat.7 specification and supports not only PROFINET but also the protocol types EtherCAT and EtherNet/IP. The cable with PUR sheath is resistant to oils and UV radiation, halogen-free, flame-retardant, and can be used in a temperature range of -40 to 85 °C.

The patch cables are suitable for device connections between machines and end devices in protected control cabinets. The molded RJ45 connectors with latch lever protection and length marking provide a secure grip when plugging and unplugging.

Fire protection class: Not relevant
Burning dripping: Not relevant
Smoke development: Not relevant
Acid development: Not relevant
Protection class: IP20
Short description: S/FTP Cat.6A (ISO/IEC) PUR
Length: 1 m
EAN: 4018359501778.

Key specifications

Patch cable type
Copper cable
Contact assignment
straight
Item number
36775014

General information

Manufacturer
Telegärtner
Category
Network cables
Manufacturer no.
L80400A0006
Release date
28.6.2023

Colour

Cable colour
Green

Material

Material
Polyurethane (PUR)
Material of the isolation
Polyurethane

Cable properties

Connection A
RJ45
Connection B
RJ45
Cable Application
Network
Cable design
Flat cable
Plug type
Gold-plated contacts
Cable connection
Connection (m/m)
American Wire Gauge (AWG)
26
Temperature range
-40 °C to 85 °C

Patch cable properties

Patch cable type
Copper cable
Patch cable Features
Handle protection
Max. data transfer rate
1 GB/s

Twisted-pair cable properties

Cable category
CAT6a
Contact assignment
straight
Shield
S/FTP

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 x
Scope of delivery
FTP Cat.6A 100017307, Patchk.S

Product dimensions

Length
1 m
Depth
1000 mm
