Product details
TE Sensors Ultrasonic Switch Sensor XX9V1A1F1M12
Manufacturer: TE Sensors
Designation: Analog ultrasonic switch sensor, 18mm
Type: XX9V1A1F1M12
Output type: 0 V ... 10 V
Electrical connection type: M12 connector
Switch output type: other
Switch function type: other
Blind zone: 51 mm
Sensor width: 18 mm
Sensor height: 33 mm
Sensor length: 60 mm
Sensor diameter: 18 mm
Adjustable distance: 51..508 mm
Adjustment method: Teach-In
Measurement range length: 51..508 mm
Protection class (IP): IP67
Explosion protection category for gas: none
Explosion protection category for dust: none
Housing design: rectangular
Interface standard: analog
No-load current: 40 mA
Relative linearity deviation: 0 %
Max. output current: 0 mA
Ambient temperature: -20..65 °C
Supply voltage: 12..24 V
Relative repeat accuracy: 1.27 %
Switching frequency: 0 Hz
Voltage type: DC
Synchronization possible: no
Material of the active area of the sensor: plastic
Material of the housing: plastic
Material of the cable sheath: other
TE Sensors Ultrasonic Switch Sensor XX9V1A1F1M12: additional details
This Telemecanique Sensor OsiSense flat ultrasonic sensor features a VALOX housing. It has a switching distance of 0.5 m (adjustable via teach mode) and an M12 connector. It operates with a supply voltage of 12 to 24 VDC and has an analog output of 0 to 10 V. This universally applicable rectangular ultrasonic sensor with analog output can be directly mounted on a surface or bracket thanks to its cylindrical thread and two mounting nuts, and it complies with the IEC 60947-5-2 standard.
