RS PRO PCB mount transformer,12VA 2x12V o/p
Delivered between Wed, 29.4. and Mon, 4.5.
More than 10 pieces in stock at third-party supplier
More than 10 pieces in stock at third-party supplier
Supplied by
Distrelec CH
Free shipping starting at 50.–
Performance2
Product details
Secondary nominal voltage: 12V AC
Nominal power: 12VA
Primary nominal voltage: 115V AC, 230V AC
Number of outputs: 2
Length: 54mm
Width: 45mm
Depth: 41mm
Dimensions: 54 x 45 x 41mm
Weight: 400g
Mounting type: Through-hole mounting
Operating frequency min.: 50Hz
Operating frequency max.: 60Hz
Transformers for PCB mounting with 115/230V AC. Two primary windings for 115V AC and 50/60Hz, which can be connected in series for operation with 230V or in parallel for operation with 115V. Fully encapsulated windings with 100% electrical testing and dielectric testing according to BS3535 and EN60742.
transformer type | PCB transformer |
input voltage | 230 V |
Output voltage | 12 V |
Power | 12 W |
Item number | 9945746 |
Manufacturer | RS PRO |
Category | Transformer |
Manufacturer no. | 504448 |
Release date | 22.10.2018 |
transformer type | PCB transformer |
input voltage | 230 V |
Output voltage | 12 V |
Power | 12 W |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂ emissions | 95.84 kg |
Climate contribution | CHF 1.69 |
Length | 54 mm |
Width | 45 mm |
Height | 54 mm |
Weight | 400 g |
