Phoenix Contact M12 SPEEDCON, X-coded,8W, Ethernet CAT6A

Ratings
Delivered between Thu, 19.6. and Fri, 20.6.
More than 10 items in stock at third-party supplier
Supplied by
Conrad CH

Product details

Number of contacts: 8
Mounting type: Cable mounting
Connector size: M12
Connection type: IDC
Rated current: 600 mA
IP class: IP65, IP67
Contact gender: Male
Operating voltage: 57 V dc
Connection type: Pluggable
Housing orientation: Straight
Series: SPEEDCON
Housing material: Zinc die-cast
Maximum operating temperature: +85 °C

M12 bus system connector utilizing SPEEDCON connections for easy installation. Shielded Cat6 connections that provide a high level of protection and can be safely used in field applications. The SPEEDCON connection method not only saves installation time but can also be easily performed in the field. Data transmission: 10 GB/s, Cat6a versions available in straight and angled orientations to ensure suitability for your application.

Key specifications

Plug type
DC connector
Cable + connector type
Various
Item number
10131950

General information

Manufacturer
Phoenix Contact
Category
Cables + Plugs
Manufacturer no.
1411043
Release date
22.11.2018
External links
Manufacturer's site (de)

Material

Material group
Metal
Material
Die-cast zinc, Nickel plated

Cable + Connector Features

Cable + connector type
Various
Plug type
DC connector
Compatible hardware
Various
Max. temperature
85 °C
Min. temperature
-40 °C
mounting type
Cable installation
Manufacturer Type
SACC-MSX-8Q #1411043
Connectors Design
Plug, straight
Number of cores
8 x

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece
Scope of delivery
1

Product dimensions

Length
8.70 cm
Width
8.60 cm
Height
4.30 cm
Weight
43.90 g
