The MAG series was developed through rigorous quality testing and designed as a symbol of robustness and durability. It is aimed at providing an excellent user experience and features a straightforward installation process as well as a user-friendly interface, making it the best choice for beginners.
Processor family | Ryzen 1st Gen, Ryzen 2nd Gen, Ryzen 3rd generation, Ryzen 5th Gen |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | M.2 SATA (2x), S-ATA III (6x) |
Mainboard features | Front panel audio connector |
Documents | |
Item number | 13299606 |
Manufacturer | MSI |
Category | Motherboards |
Manufacturer no. | 7C91-001R |
Release date | 5.6.2020 |
Form factor | ATX |
Socket | AM4 |
Chipset | AMD B550 |
Mainboard features | Front panel audio connector |
Operating system compatibility | Linux, Windows 10, Windows 11 Home, Windows 7, Windows 8 |
BIOS type | UEFI AMI |
Processor family | Ryzen 1st Gen, Ryzen 2nd Gen, Ryzen 3rd generation, Ryzen 5th Gen |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Memory chip | DDR4-2133, DDR4-2400, DDR4-2666, DDR4-2800, DDR4-2933, DDR4-3200 |
Max. RAM OC | 4866 MHz |
Supported memory speed | 1866 MHz, 2133 MHz, 2400 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz |
Memory type | DDR4-RAM |
RAM buffer | Unbuffered |
Video connections | DisplayPort (1x), HDMI (1x) |
Multi-GPU technology | AMD 2-Way CrossFireX |
Network connections | RJ45 Gigabit Ethernet (2x) |
Ethernet controller brand | Realtek |
Ethernet controller | Realtek RTL8111H, Realtek RTL8125B |
Max. port speed | 1 Gbit/s |
Chip | Realtek ALC1200 |
Audio channel | 7.1 Channel |
Audio Connections | Digital Audio Out (1x) |
Internal connection options | M.2 SATA (2x), S-ATA III (6x) |
Expansion slot | PCI Express x16 (2x) |
PCI express version (max.) | 4 |
Number of fan connector | 6 |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 1 (2x) |
Power connectors | 24-pin ATX |
Country of origin | China |
Manufacturer commitment | SBTi |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Sata Cables |
Length | 244 mm |
Width | 305 mm |
Height | 86 mm |
Weight | 1000 g |
Length | 34.50 cm |
Width | 27 cm |
Height | 9 cm |
Weight | 1.90 kg |
