Gigabyte B760M D3HP

LGA 1700, Intel B760, mATX
Ratings
BrandMore from Gigabyte
Delivered between Wed, 28.5. and Sat, 31.5.
8 items in stock at supplier

Product details

GIGABYTE Ultra Durable motherboards, equipped with optimal components, offer premium performance and a timeless platform. The ultimate in connectivity with blazing fast data transfer speeds through the network and next-generation storage. Innovative and intuitive hardware, software and BIOS interface design to personalise your style. Smart Fan 6 ensures optimal cooling and quiet operation of your gaming PC, with support for PWM/DC fans and pumps, customisable settings and intuitive temperature monitoring.

Key specifications

Processor family
Pentium Gold
Memory type
DDR5 RAM
Number of memory modules (RAM)
4 x
Internal connection options
M.2 (2x)
Mainboard features
Parallel header, Reset button, S/PDIF header, Serial header
Item number
49849070

General information

Manufacturer
Gigabyte
Category
Motherboards
Manufacturer no.
B760M D3HP
Release date
1.10.2024

Motherboard properties

Form factor
Micro ATX (mATX)
Socket
LGA 1700
Chipset
Intel B760
Mainboard features
Parallel header, Reset button, S/PDIF header, Serial header
Operating system compatibility
Linux, Windows 10
BIOS type
UEFI AMI

Processor

Processor family
Pentium Gold

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
4 x
Max. memory (RAM)
256 GB
Memory chip
DDR5
Max. RAM OC
7600 MHz
Supported memory speed
4400 MHz, 4800 MHz, 5200 MHz, 5600 MHz
Memory type
DDR5 RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
DisplayPort (1x), HDMI (1x), VGA (1x)

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Realtek
Ethernet controller
Realtek RTL8111H
Max. port speed
1 Gbit/s

Audio

Audio channel
8.0 Channel

Data storage

RAID configuration
0, 1, 10, 5

Internal interfaces

Internal connection options
M.2 (2x)
Expansion slot
PCI Express x1 (Gen 3) (2x), PCI Express x16 (Gen 4) (1x)
PCI express version (max.)
4
Number of fan connector
3

Further connections

USB ports
USB-A
Exact USB ports
USB-A 3.2 Gen 1 (2x), USB-A 3.2 Gen 1 (3x)

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Origin

Country of origin
China, Germany, Taiwan

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
244 mm
Width
244 mm
Height
35 mm
Weight
720 g

Package dimensions

Length
27.40 cm
Width
27.30 cm
Height
5.90 cm
Weight
895 g
