Vortice Lineo 150 Quiet ES

Delivered between Wed, 18.6. and Fri, 27.6.
Supplied by

Product details

Dimensions and technical details:

  • Voltage: 220-240 V ~ 50/60 Hz
  • 0-10 V interface
  • Housing color: black
  • Housing material: polypropylene
  • Nominal size: 150 mm
  • Speed levels: 1
  • Wattage: 31 W
  • Current consumption: 0.34 A
  • Revolutions per minute: 2030
  • Airflow rate: 515 m³/h
  • Sound pressure level Lp-3m: 30.2 dB(A)
  • Total pressure Pmax: 237.3 Pa
  • Max. temperature of transported air: +60°C
  • Protection class: IP45
  • Insulation class: II
  • Weight: 5.4 kg
  • Thermal overload protection
  • Includes mounting bracket
  • Optional speed controller sold separately
  • Mounting position: any position
  • Fan unit can be removed quickly for cleaning and maintenance
  • Classification of fire E-d2 according to European Standard EN 13501-1

Dimensions in mm:

  • A: 232
  • B: 320.6
  • C: 685
  • Ø D: 147
  • E: 145
  • F: 261.5
  • G: 170
  • H: 132
  • L: 85
  • Ø M: 5.5
  • N: 360.
