Steinel 064372

Steinel IR presence detector IR QuattroHD #064372

Manufacturer: Steinel
Designation: IR presence detector flush-mounted
Type: IR QuattroHD #064372
Bus system KNX radio: No
Bus system radio bus: No
Bus system LON: No
Bus system Powernet: No
Mounting type: Flush-mounted
Material: Plastic
Material quality: Thermoplastic
Surface protection: Other
Colour: White
RAL number (similar): 9003
Transparent: No
Anti-creep protection/back field monitoring: Yes
Animal track: No
Staircase monitoring: No
Teach function for response brightness: Yes
Self-learning switch-off delay: No
Optimum mounting height: 2.8 m
Max. range to one side: 12 m
Max. range to the other side: 12 m
Range to one side: 12 m
Max. range frontal: 12 m
Detection field diameter on floor: 9 m
Detection angle horizontal: 360°

Designed for the finest detection in the largest detection range among our infrared presence detectors. Ideal for open-plan offices or classrooms. The IR Quattro HD-2 features 360° detection and 5,200 switching zones. Wireless setting and networking via Bluetooth. Pyro sensors can be controlled individually. Suitable for recessed ceiling mounting as well as flush-mounted and surface-mounted variants. Measured variables include presence function, brightness, temperature, and humidity. Mounting height max: 10 m. Range: 81 m² (radial), 576 m² (tangential). EAN: 4007841064372.
