Spelsberg 72074501 GEOS-S 4050-22-o/SH Control cabinet

Ratings
BrandMore from Spelsberg
Delivered between Fri, 29.8. and Tue, 16.9.
free shipping

Product details

Spelsberg switch cabinet GEOS-S 4050-22-o/SH
Manufacturer: Spelsberg
Designation: Switch cabinet
Type: GEOS-S 4050-22-o/SH
Width: 400 mm
Height: 500 mm
Depth: 226 mm
Material: Plastic
Material quality: Other
Finish: Other
Colour: Grey
RAL number: 7035
Free-standing: No
Floor-standing wall model: No
Suitable for wall mounting: Yes
Corner model: No
Intermediate mounting: No
Can be coupled: No
With mounting plate: No
Mounting plate depth-adjustable: No
Suitable for wall mounting: No
Pole mounting: Yes
Number of doors: 1
Suitable for metric mounting: No
Suitable for outdoor installation: Yes
Pitched roof: No
EMC version: No
With viewing door: No
With ventilation door: No
With rear door: No
Impact resistance: IK09
Protection class (IP): IP66
Protection class (NEMA): 4X
Heat loss capacity (Delta T 20 K) according to IEC/TR 60890: 43.3 W
Max. permissible load of the enclosure/cabinet: Yes
Max. permissible load on enclosure/cabinet to IEC 62208: 245 N
Max. permissible load on door(s) to IEC 62208: 245 N
Max. permissible load of the door(s) to IEC 62208: 50 N

Spelsberg enclosure GEOS-S 4050-22-o/SH: more details
Enclosure industrial quality, suitable for installation in harsh environments and in unprotected outdoor areas. Box and frame: glass-fibre reinforced polycarbonate, grey, similar to RAL 7035; door: polycarbonate. Pivot lever to accept profile half cylinder according to DIN 18252, with grey door.
Dimensions: 400 x 500 x 226 mm.
EAN: 4013902646111.

Key specifications

Protection type (IP code)
IP66, IP67
Length
500 mm
Width
400 mm
Height
226 mm
Item number
22933716

General information

Manufacturer
Spelsberg
Category
Wiring closet technology
Manufacturer no.
72074501
Release date
25.10.2022
Sales rank in Category Wiring closet technology
65 of 11443

Colour

Colour
Grey
Exact colour description
RAL 7035

Material

Material group
Plastic
Material
Polycarbonate

Distribution cabinet technology Features

Area of use
Outside
Protection type (IP code)
IP66, IP67
number of poles
1
Fuse size
Type 4X

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
500 mm
Width
400 mm
Height
226 mm
Depth
226 mm

Package dimensions

Length
50.10 cm
Width
43 cm
Height
30 cm
Weight
6.16 kg

30-day right of return if unopened
24 Months Warranty (Bring-in)
