Sick WL12G-3B2531S37

2 m
Ratings
BrandMore from Sick
Delivered between Sat, 22.8. and Fri, 4.9.
1 item ordered
free shipping

Product details

The WL12G-3B2531S37 from Sick is a highly advanced motion sensor that functions as a light switch and light barrier. This device utilizes the principle of a reflective light barrier and offers a maximum switching range of 0 to 2 meters. The sensor operates on a detection principle based on autocolimation, meaning that no minimum distance to the reflector is required. The WL12G-3B2531S37 is equipped with both PNP and NPN switching outputs and can be configured for both light-on and dark-on operation. Connection is made via a 5-pin M12 connector, allowing for easy integration into existing systems. The light emitter uses visible red light generated by an LED. The zinc die-cast housing ensures a robust design that meets the demands of industrial applications.

  • Detection angle of 1.5 degrees for precise detection
  • IP66 protection class for high resistance to dust and water
  • Adjustable sensitivity via potentiometer
  • Robust zinc die-cast housing
  • Suitable for use in demanding environments.

Key specifications

type of sensor
Optical
Range
2 m

General information

Item number
30349353
Manufacturer
Sick
Category
Motion sensors
Manufacturer No.
1044111
Release date
28.4.2023

Material

Material group
Metal
Material
Die-cast zinc

Motion sensor properties

type of sensor
Optical
Range
2 m
Protection type (IP code)
IP66, IP67, IP69K

Smart home features

Smart home
Not compatible

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
22.15 kg
Climate contribution
CHF 0.52

Product dimensions

Length
4.20 cm
Height
4.85 cm
Weight
120 g
