Sick HL18-P4A3BA

6.50 m
Ratings
BrandMore from Sick
Delivered between Mon, 18.5. and Thu, 21.5.
Only 4 pieces in stock at third-party supplier
Supplied by
free shipping

Product details

Sick hybrid photoelectric sensor HL18-P4A3BA
Manufacturer: Sick
Designation: Hybrid photoelectric sensor SureSense
Type: HL18-P4A3BA
Rated switching distance: 5000 mm
Max. switching distance: 6500 mm
Max. output current: 100 mA
Adjustment method: Other
Number of contact outputs with signaling function: 1
Electrical connection version: M12 plug connector
Switching output version: PNP
Switching function version: Antivalent
Equipment protection class: Protection class 3
Explosion protection category for gas: None
Explosion protection category for dust: None
Enclosure design: Special design
Width of sensor: 16.2 mm
Height of sensor: 48.5 mm
Length of sensor: 31.8 mm
Sensing function: Light/dark switching
Material of optical surface: Plastic
Material of enclosure: Plastic
Max. output current at the safe output: 100 mA
Ambient temperature: -40 °C
Response time: 0.5 ms
Range of protective field: 6.5 m
Switching frequency: 1000 Hz
Rated control supply voltage Us at DC: 10...30 V
Voltage type: DC
Laser protection class: Other
Wavelength of the sensor: 631 nm
Light type: Red light polarized
Protection class (IP): IP67

Further details:
Hybrid photoelectric sensors, SureSense, HL18-P4A3BA
Device version: Standard
Mounting type: M18, head/side (24.1 - 25.4 mm)
Sensor/detection principle: Retro-reflective photoelectric sensor, double lens
Switching distance: 6.5 m
Light transmitter, light type: PinPoint LED, visible red light
Voltage type: DC
Switching output Q1: PNP, light switching
Switching output Q2: PNP, dark switching
Connection type: Plug M12, 4-pin
EAN: 4047084362231.

Key specifications

Exact colour description
Blue
Range
6.50 m

General information

Item number
31287670
Manufacturer
Sick
Category
Motion sensors
Manufacturer No.
1071743
Release date
22.9.2022

Colour

Colour
Blue
Exact colour description
Blue

Material

Material group
Plastic
Material
Plastic, VISTAL®

Motion sensor properties

Range
6.50 m
Protection type (IP code)
IP69K

Origin

Country of origin
USA

Voluntary climate contribution

CO₂ emissions
3.32 kg
Climate contribution
CHF 0.11

Scope of delivery

Scope of delivery
Black, Fastening nut (1x), Flat, M18, Plastic

Product dimensions

Length
5 cm
Width
3.20 cm
Height
4.85 cm
