Sick Diffuse reflection light scanner

Sick Diffuse reflection light scanner WTB12-3P2413 Manufacturer :Sick Designation :Diffuse reflection light scanner Type :WTB12-3P2413 Rated operating distance :600 mm Max. Switching distance :600 mm Version of interface for safety-related communication :other Version of electrical connection :M12 plug connector Version of switching output :PNP Version of switching function :antivalent Equipment protection class :Protection class 3 Housing design :Rectangular Sensor width :15.6 mm Sensor height :48.5 mm Sensor length :42 mm Sensing function :Light/dark switching Optical surface material :Plastic Housing material :Metal Max. output current at safe output :100 mA Max. output current at safe output :100 mA Ambient temperature :60 °C Response time :0.33 ms Switching frequency :1500 Hz Rated control supply voltage Us at AC 50 Hz :10 V Voltage type :DC Wavelength of the sensor :850 nm Light type :Infrared light Light spot :15 mm² Protection class (IP) :IP66 Sick diffuse reflection sensor WTB12-3P2413: Further details Small photoelectric sensors, W12, WTB12-3P2413, Device type: Diffuse sensors and photoelectric sensors, Switching distance max.20 mm ... 600 mm, Sensor principle: Diffuse reflection sensor, Detection principle: Background suppression, Switching output: PNP, Switching mode: Light/dark switching, Connection type: M12 plug, 4-pin, Light emitter: LED, Type of light: Infrared light, Setting: Teach-in button, Included in delivery: 2 x BEF-KH-W12 clamp brackets, incl. screws, EAN: 4047084140976.
