OBO Bettermann SDB 12 PS small distributor

Manufacturer: OBO Bettermann
Designation: Small distributor for max. 12 TE
Type: SDB 12 PS
Mounting type: Surface-mounted
Number of rows: 1
Width in division units: 12
Type of cover: Cover version
Cover: with cut-out
Transparent cover/door: yes
Material of housing: Plastic
Height: 125 mm
Width: 202 mm
Depth: 125 mm
DIN rail: yes
With mounting plate: no
Mounting option: yes
EMC version: no
Colour: grey
RAL number: 7035
Protection class (IP): IP66
With lock: no

OBO Bettermann SDB 12 PS small distribution board: further details
Small distribution board with terminal strip for surface mounting, for power sub-distribution indoors and in protected outdoor areas, in accordance with IEC 439-3. With pre-mounted 35 mm top-hat rail. Protection class IP66 and degree of protection IK06. Transparent cover for screwing, with cut-out. Protective insulation for a maximum of 12 pitch units. Terminal strip set consisting of: 3 PE/N terminals each with 4x 16 mm² screw terminals, mini top-hat rail, assembly instructions and fixing kit, identification labels for connected loads, 8 elastic cable glands Ø 20 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 25 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 25 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 20 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 20 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 20 mm for cable diameters 0-17 mm, 1 elastic cable gland Ø 25 mm for cable diameters 0-22 mm, 1 elastic cable gland Ø 32 mm for cable diameters 0-28 mm, 10 knock-out openings Ø 20 mm each top and bottom, 1 combined knock-out opening Ø 20/25/32 mm each top and bottom, 4 screw caps.
