OBO Bettermann OBO SDB 12L PS Small distribution board without terminal strip, for 12 TE light grey
Delivered between Wed, 10.12. and Fri, 26.12.
free shipping
Product details
Small distribution board for surface mounting, designed for electrical sub-distribution in indoor and protected outdoor areas, in accordance with IEC 439-3. With pre-mounted 35 mm DIN rail. Protection class IP66 and impact resistance rating IK06. Transparent screw-on lid with cut-out. Protection insulated for a maximum of 12 modular units. 11 knock-out openings Ø 20 mm at the top and bottom. 1 combined knock-out opening Ø 20/25/32 mm at the top and bottom. 4 screw cover caps.
Distribution cabinet type | Small distribution board |
mounting style | Finery |
Length | 12.60 cm |
Width | 20.20 cm |
Height | 12.60 cm |
Item number | 32151375 |
Manufacturer | OBO Bettermann |
Category | Electrical enclosures |
Manufacturer no. | 2008832 |
Release date | 16.11.2022 |
Colour | Grey |
Exact colour description | Grey (RAL 7035) |
Material group | Plastic |
Material | Plastic |
Distribution cabinet type | Small distribution board |
mounting style | Finery |
Protection type (IP code) | IP66 |
Country of origin | Germany, Hungary |
CO₂-Emission | |
Climate contribution |
Length | 12.60 cm |
Width | 20.20 cm |
Height | 12.60 cm |
