Jumo DRUCKMESS 40 - Transmitter pressure -20...+100°C up to 40 bar (00546124)

Jumo Pressure Transmitter Basic 00546124 Manufacturer :Jumo Designation :Pressure Transmitter Basic 0-40 bar rel,4-20mA Type :00546124 Process temperature :-20..125 °C Analogue output 0 mA ... 20 mA :no Analogue output 4 mA ... 20 mA :yes Analogue output 0 V ... 2 V :no Analogue output 0 V ... 5 V :no Analogue output 0 V ... 10 V :no Analogue output 2 V ... 10 V :no Ambient temperature :-20..85 °C Weight :0.07 kg Jumo pressure transmitter Basic 00546124: more details The pressure transmitter can be used in liquid and gaseous media. The innovative and patented sensor design of the specially developed ceramic sensor results in an excellent long-term stability of 0.2 %. FPM is used as the sealing material. The temperature application range is from -20 to +125 °C. Thanks to design measures, the pressure transmitter achieves excellent vibration resistance and enables use under high vibration loads, such as those that occur in commercial vehicles. The electrical connection is made through a cable socket. , EAN: 4053877006459.
