iGet SECURITY P3 security device components

Ceiling Wireless Motion Detector PIR Detector

This is a wireless PIR motion detector designed for ceiling installation, primarily intended for alarms from iGET SECURITY. This PIR detector is also compatible with many alarms from other brands. For compatibility information, please contact our technical support.

Main features:

• The detector is suitable for all rooms where monitoring through motion detection is required and ceiling installation is appropriate.
• Easy expansion of the basic alarm set.
• Motion detection based on infrared radiation.
• Includes two signal LEDs: Red indicates motion detection, Yellow informs about low battery status.
• Battery life of up to one year, depending on the number of detections.
• When installed at a minimum height of 2.4 m, the detector has a circular detection range of 360° with a diameter of 6 m.
• When installed at a maximum height of 3.6 m, the detector has a circular detection range of 360° with a diameter of 9 m.

Specifications:

• Transmission frequency: 433 MHz
• Operating temperature: -10°C to +50°C
• Operating humidity: 5% to 95%
• Coding used: 2262/1527
• Operating voltage: 9V battery, type 6F22
• Coverage: 6 to 9 m
• Signal range to the control unit: up to 80 m with direct line of sight
• Compatible with iGET SECURITY M3B and M2B.
