ELSO Dimmer insert 40-315W/VA ELG174201

Elso dimmer insert 40-315W/VA ELG174201

Manufacturer: Elso
Designation: Dimmer insert 40-315W/VA
Phase cut-off: No
Type: ELG174201
Composition: Basic element
Operating mode: Rotary/push button
App control via Bluetooth: No
Dimming phase control: No
Dimming phase cut: Yes
Series dimmer: No
Load type: Capacitive load
Extension input: No
Light value memory: Yes
Usable with button: No
Usable with motion detector: No
Usable with presence detector: No
Usable with timer: No
Can be used with radio button: No
Can be used with IR button: No
Mounting type: Flush-mounted
Mounting type: Fastening with screw
Material: Plastic
Material quality: Thermoplastic
Halogen-free: Yes
Surface protection: Untreated
Colour: Grey
Transparent: No
Suitable for protection class (IP): IP20
Rated voltage: 230 V
Frequency: 50 Hz
Control voltage: 230 V
Rated power resistive load: 20-315 W
Rated power capacitive load: 20-315 VA
Type of connection: Screw terminal
Wire cross-section: 2.5 mm²
Unit width: 71 mm
Unit height: 71 mm
Unit depth: 29 mm
Min. device box depth: 46 mm
Compatible with Apple HomeKit: No
Compatible with Google Assistant: No
Compatible with Amazon Alexa: No
IFTTT support available: No

Elso dimmer insert 40-315W/VA ELG174201: More details
With push-button off/changeover switch for incandescent lamps and dimmable electronic transformers, 230 V, 50 Hz.
With reversible short-circuit and thermal protection, noiseless function, memory function.
Type SBD315RC.
EAN: 4013984193268.
