Two-part design for doors made of metal profiles, withstands high pressure and tensile forces. The cover piece is screwed on for enhanced burglary protection. Usable for both DIN left and DIN right configurations, with maintenance-free bearing points. Adjustability includes horizontal +/- 2.5 mm, vertical +3 / -2 mm, and sealing pressure +/- 0.5 mm.
Material group | Metal |
Material | Aluminium |
Item number | 13945343 |
Manufacturer | Dr. Hahn |
Category | Door hinge |
Manufacturer no. | M 701 1 E000 |
Release date | 6.10.2020 |
Sales rank in Category Door hinge | 28 of 1318 |
Colour | White |
Exact colour description | Colorless |
Material group | Metal |
Material | Aluminium |
Scope of application | Door |
Opening angle | 20° |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 20.50 mm |
Width | 20.50 mm |
Height | 42 mm |
Weight | 140000 g |
Length | 13 cm |
Width | 11 cm |
Height | 5 cm |
Weight | 310 g |
